YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
63
IM 01E21A02-03EN
5.1.10 Temperature Setting
The temperature setting is required when calculating the calorie based on the temperature
di󰀨erencefromthetemperaturethatistakeninviaMAOFB.
For details about the calorie measurement, refer to Subsection 5.5.6.
This parameter can be used only for AXG, not for AXW.
Thesettingcanbeconguredwiththefollowingparameters.
Menu path
Display Devicesetup►Detailedsetup►Provar►Temperature►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►STB►DeviceConguration►Conguration►Process
Variables►Temperature►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 101 Std temperature Standard Temperature
Speciesthereference
standard temperature for using
the temperature-based density
correction function.
STB 107 Fixed temperature CaloricFixedTemp
Speciesthereference
temperature to use for the
calorie calculation with
temperaturedi󰀨erencefromthe
temperature which is input from
the outside.
Display Devicesetup►Detailedsetup►Provar►Temperature►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►STB►DeviceConguration►QueryDevice►SnsrTBOriginal
Parameters(Part2)►Page1►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 104 Meas temperature Measured Temperature
Displays the temperature that is
input from the outside.
