YOKOGAWA ADMAG TI Series

<6. Parameter Lists>
214
IM 01E21A02-03EN
6.7 DI Function Block
Relative
Index
Index
Parameter
Name
Default Value
Write
Mode
Description
DI1 DI2 DI3
0 6000 6100 6200 Block Header
DI1:“DI1”
DI2:“DI2”
DI3:“DI3”
O/S
Information on this block,
such as Block Tag, DD
Revision, Execution, etc.
1 6001 6101 6201 ST_REV 0 -
Represents the revision
level of the setting
parameter of the own
block. This revision is
updated if the setpoint is
changed. Used to check
for parameter change, etc.
2 6002 6102 6202 TAG_DESC Space(32characters) AUTO
Universal parameter
to store a comment
explaining tag contents.
3 6003 6103 6203 STRATEGY 1 AUTO
Universal parameter
intended to be used for
the high-level system to
separate function blocks.
4 6004 6104 6204 ALERT_KEY 1 AUTO
Keyinformationtoidentify
where an alert takes place.
Generally, this parameter
is used by the high-
level system to identify
specicareasinaplant
that are under the control
ofspecicoperators,to
separate necessary alerts
only. This is one of the
universal parameters.
5 6005 6105 6205 MODE_BLK
0x08(Auto)
0x08(Auto)
0x88(Auto,O/S)
0x08(Auto)
AUTO
-
AUTO
AUTO
Universal parameter to
show a block operation
state. Consists of Actual
mode, Target mode, Permit
mode and Normal mode.
6 6006 6106 6206 BLOCK_ERR 0x0000 -
Indicates the error statuses
related to the own block.
7 6007 6107 6207 PV_D
0x1C
0
-
-
The primary discrete value
(orprocessvalue)for
execution of the block’s
functions.
8 6008 6108 6208 OUT_D
0x1C
0
-
MAN
Indicates the value and
status of output value.
9 6009 6109 6209 SIMULATE_D
0(Bad:NonSpecic:NotLimited)
0(State0)
0(Bad:NonSpecic:NotLimited)
0(State0)
1(Disabled)
AUTO
AUTO
-
-
AUTO
Selects whether to use
a limit switch input which
is actually input from the
transducer block, or to use
avaluespeciedbyan
operator. If the simulation
is set to Disable, the actual
value and status will be
reected.
10 6010 6110 6210 XD_STATE 0 AUTO Not used for this product.
11 6011 6111 6211 OUT_STATE 0 AUTO Not used for this product.
