6.3 Diagnosis Transducer Block
 List of diagnosis transducer block parameter
Relative
Index
Index Parameter Name Default Value
Write
Mode
Description
0 2500 Block Header DTB O/S
Information on this block, such as
Block Tag, DD Revision, Execution,
etc.
1 2501 ST_REV 0 -
Represents the revision level of
the setting parameter of the own
block. This revision is updated if the
setpoint is changed. Used to check
for parameter change, etc.
2 2502 TAG_DESC
Space(32
characters)
AUTO
Universal parameter to store a
comment explaining tag contents.
3 2503 STRATEGY 1 AUTO
Universal parameter intended to be
used for the high-level system to
separate function blocks.
4 2504 ALERT_KEY 1 AUTO
Keyinformationtoidentifywhere
an alert takes place. Generally, this
parameter is used by the high-level
systemtoidentifyspecicareasin
a plant that are under the control
ofspecicoperators,toseparate
necessary alerts only. This is one of
the universal parameters.
5 2505 MODE_BLK
0x08(Auto)
0x08(Auto)
0x88(Auto,O/S)
0x08(Auto)
AUTO
-
AUTO
AUTO
Universal parameter to show a block
operation state. Consists of Actual
mode, Target mode, Permit mode
and Normal mode.
6 2506 BLOCK_ERR 0x0000 -
Indicates the error statuses related
to the own block.
7 2507 UPDATE_EVT
0(Uninitialized)
0(Uninitialized)
0,0
0
0
AUTO
-
-
-
-
Indicates contents of the event when
anupdateevent(achangetothe
setpoint)occurs.
8 2508 BLOCK_ALM
0(Uninitialized)
0(Uninitialized)
0,0
0(Other)
0
AUTO
-
-
-
-
Indicates contents of the alarm when
a block alarm occurs.
9 2509
TRANSDUCER_
DIRECTORY
1
2510
-
-
Parameter to store the index of the
transducer included in the device.
10 2510
TRANSDUCER_
TYPE
32896(Diagnostic
TB)
- Indicates the device type.
11 2511
TRANSDUCER_
TYPE_VER
0x0000 - Indicates the version of the device.
12 2512 XD_ERROR 0 -
Stores the most important error
among errors which are occurring in
the sensor transducer block.
13 2513
COLLECTION_
DIRECTORY
0 -
Stores indexes of important
parameters in the transducer block
and the item ID of the corresponding
DD.
14 2514
ADHESION_
VALUE
0
0
-
-
See 5.1.3.
15 2515
ADHESION_
VALUE_UNIT
1283(MOhm) - Shows the adhesion resistance unit.
16 2516
ELECTRODE_A_
VALUE
0
0
-
-
See 5.1.3.
