YOKOGAWA ADMAG TI Series

<5. Functions>
67
IM 01E21A02-03EN
 Setting conversion factor for scaling
Menu path
Display Devicesetup►Detailedsetup►Totalizer►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►STB►DeviceConguration►Conguration►Totalizer►(see
below)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 66
Totalizer1►
Conv factor
Totalizer1►Total1ConvFactor
Speciestheconversion
factor of totalizer 1.
STB 75
Totalizer2►
Conv factor
Totalizer2►Total2ConvFactor
Speciestheconversion
factor of totalizer 2.
 Display of the totalized count value that is scaled with the conversion
factor
Menu path
Display Devicesetup►Processvariables►Totalizer►(seebelow)
F
OUNDATION
Fieldbus
-
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
- - Totalizer 1 count -
Displays the scaled totalized
value of totalizer 1.
- - Totalizer 2 count -
Displays the scaled totalized
value of totalizer 2.
Example:
Set the unit of totalizer 2 to “m
3
”andtheconversionfactorto“2”.
-> If the totalized value of totalizer 2 is “10.123 m
3
”,thetotalizedvalueisscaledto“10.123÷2=5”.
5.2.3 Totalization Switch Function
Whenatargetvalue(threshold)tototalizeisspecied,itcanbeusedasatotalizationswitch
function.Thetotalizationswitchfunctioncancomparethespeciedtargetvaluewiththetotalized
value and output the result in status output.
Thestatusoutputisactivewhilethetotalizedvalueexceedsthespeciedtargetvalue.
For details about the output, active direction, and status output function setting for each terminal,
refer to Section 5.14. However, the status output function can be used only when disconnected
o󰀪inefromthecontrolloop.
Thesettingcanbeconguredwiththefollowingparameters.
Menu path
Display Devicesetup►Detailedsetup►Totalizer►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►STB►DeviceConguration►Conguration►Totalizer►(see
below)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 74 Totalizer1►Setpoint Totalizer1►Total1Setpoint
Speciesthetargetvalueof
totalizer 1.
STB 83 Totalizer2►Setpoint Totalizer2►Total2Setpoint
Speciesthetargetvalueof
totalizer 2.
