<Appendix 6. Software Download>
301
IM 01E21A02-03EN
A6.9 System/Network Management VFD
Parameter related to Software Download
Table A6.5 System/Network Management VFD Parameter Write Mode R/W: Read/Write, R: Read Only
Index
(SM)
Parameter Name
(Sub-
Index)
Sub-parameter Name Default Value
Write
Mode
Remarks
310 DWNLD_PROPERTY 0 R
1 Download Class 1 R
2
Write Rsp Returned For
ACTIVATE
1 R
3
Write Rsp Returned For
PREPARE
1 R
4 Reserved 0 -
5 ReadyForDwnld Delay Secs 60 R
6 Activation Delay Secs 120 R
313
DOMAIN_
DESCRIPTOR
0 R/W
Read/write-
permitted
only for sub-
index 1
1 Command 3 R/W
2 State 1 R
3 Error Code 0 R
4 Download Domain Index 440 R
5 Download Domain Header Index 420 R
6 Activated Domain Header Index 430 R
7 Domain Name AXG4A or AXW4A R
314
DOWNLOAD_
DOMAIN_HEADER
0
1 Header Version Number 1 R
2 Header Size 0 R
3 Manufacturer ID 0x594543 R
4 Device Family
(DEV_TYPEof
RB)
R
5 Device Type
(DEV_TYPEof
RB)
R
6 Device Revision (DEV_REVofRB) R
7 DD Revision (DD_REVofRB) R
8 Software Revision
(SOFTWARE_
REVofRB)
R
9 Software Name ORIGINAL R
10 Domain Name AXG4A or AXW4A R
315
ACTIVATED_
DOMAIN_HEADER
0
1 Header Version Number 1 R
2 Header Size 44 R
3 Manufacturer ID 0x594543 R
4 Device Family
(DEV_TYPEof
RB)
R
5 Device Type
(DEV_TYPEof
RB)
R
6 Device Revision (DEV_REVofRB) R
7 DD Revision (DD_REVofRB) R
8 Software Revision
(SOFTWARE_
REVofRB)
R
9 Software Name ORIGINAL R
10 Domain Name AXG4A or AXW4A
To Next Page
