<5. Functions>
81
IM 01E21A02-03EN
5.4 Inputting External Temperature
By using the external temperature input, external temperature can be used for temperature-base
density correction calculation and calorie calculation. For details about the temperature-input
density correction calculation and calorie calculation, refer to Subsections 5.5.5 and 5.5.6.
This function can be used by making the minimum settings, such as scheduling and connecting
the external input to IN_1 of the MAO function block.
External input temperature is set with the following parameters.
Display Devicesetup►Detailedsetup►Temperature►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►STB►DeviceConguration►Conguration►Process
Variables►Temperature►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 84 Function Temp Function
Speciesaswhatvaluethe
device should handle the
external temperature input
internally.
STB 85 Unit Temp Unit
Speciestheunitofthe
external temperature input.
STB 86 URV Temp URV
Speciesthehighlimitofthe
range value of the external
temperature input.
STB 87 LRV Temp LRV
Speciesthelowlimitofthe
range value of the external
temperature input.
NOTE
WhentheexternalinputisconnectedtoIN_2-IN_8,itisnotreected.
From the table below, select the function.
Selection
Description
Display
F
OUNDATION
Fieldbus
No function No function Disables the external input function.
Monitoring Monitoring
Thoughtheexternalinputfunctionisenabled,itdoesnotinuenceow
rate calculation.
Di󰀨temperature Di󰀨temperature
Usestheexternalinputastemperaturedi󰀨erence.Caloriecalculationis
enabled if selected.
Ext temperature Ext temperature
Uses the external input as temperature. The density correction
calculationandcaloriecalculationofmassowrateareenabledif
selected.
To Next Page
