6. Parameter Lists
Note: The Write Mode column contains the modes in which each parameter is write enabled.
O/S : Write enabled in the O/S mode.
MAN : Write enabled in the Man and O/S modes.
AUTO : Write enabled in the Auto, Man, and O/S modes.
- : Unable to write
6.1 Resource Block
Relative
Index
Index Parameter Name Default Value
Write
Mode
Description
0 1000 Block Header “RB” O/S
Information on this block, such as Block
Tag, DD Revision, Execution, etc.
1 1001 ST_REV 0 -
Represents the revision level of the
setting parameter of the own block.
This revision is updated if the setpoint is
changed. Used to check for parameter
change, etc.
2 1002 TAG_DESC
Space(32
characters)
AUTO
Universal parameter to store a comment
explaining tag contents.
3 1003 STRATEGY 0 AUTO
Universal parameter intended to be
used for the high-level system to
separate function blocks.
4 1004 ALERT_KEY 0 AUTO
Keyinformationtoidentifywhereanalert
takes place. Generally, this parameter is
used by the high-level system to identify
specicareasinaplantthatareunder
thecontrolofspecicoperators,to
separate necessary alerts only. This is
one of the universal parameters.
5 1005 MODE_BLK
0x08(Auto)
0x08(Auto)
0x88(Auto,O/S)
0x08(Auto)
AUTO
-
AUTO
AUTO
Universal parameter to show a block
operation state. Consists of Actual
mode, Target mode, Permit mode and
Normal mode.
6 1006 BLOCK_ERR 0x0000 -
Indicates the error statuses related to
the own block.
7 1007 RS_STATE 1 -
Indicates the state of the resource block
in the device.
8 1008 TEST_RW
0
0
0
0
0
0
0
0.0
All spaces
All 0
0,0,0,0,0,0
0,0
0,0
0
0,0
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
AUTO
Parameter used to perform a read/write
test to the device.
9 1009 DD_RESOURCE
Space(32
characters)
-
Name of the Device Description,
including information on this resource
block.
To Next Page
