From the table below, select the use of the alarm output function.
Selection
Description
Display
F
OUNDATION
Fieldbus
0 pps 0 pps Pulse output stop
Measured value Measured value
Outputsthefrequencyorxedpulsewiththemeasuredvalue
calculated while an alarm occurs.
Last valid Last valid
Outputs the frequency or pulse with the last instantaneous value
rightbeforeanalarmoccurs(outputismonotonicincrease).
Max pps Max pps Outputs the frequency or pulse at 12500 pps.
5.14.3 Pulse Width Setting
The pulse width can be selected to use the pulse output.
Thesettingcanbeconguredwiththefollowingparameter.
Menu path
Display Devicesetup►Detailedsetup►Pulse/Statusout►PO1/SO1►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►MTB►DeviceConguration►Maintenance►Pulse/StatusOut
►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
MTB 104 Fix width Pulse 1 Fix Width Speciesthepulsewidth.
From the table below, select the pulse width.
Selection
Max. output frequency [Hz]
Display F
OUNDATION Fieldbus
0.05 ms 0.05ms 10000
0.1 ms 0.1ms 5000
0.5 ms 0.5ms 1000
1 ms 1ms 500
20 ms 20ms 25
33 ms 33ms 15
50 ms 50ms 10
100 ms 100ms 5
200 ms 200ms 2.5
330 ms 330ms 1.5
500 ms 500ms 1.0
1000 ms 1000ms 0.5
2000 ms 2000ms 0.25
Duty cycle 50%
*
Duty cycle 50%
*
-
*: Themaximumpulsewidthisupto300seconds(5minutes)when“Dutycycle50%”isselected.
 Whenoutputtingthepulsewhoseperiodisover10minutes,thepulsewidthisxedat300s.
