YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
141
IM 01E21A02-03EN
5.10 Test Mode
5.10.1 Test Mode Setting
Ifthetestmodeisexecuted,theowvelocityorthevaluetobeoutputfromaconnectionterminal
can be arbitrarily set, and a response from the device can be tested.
A warning is displayed to indicate that the test mode is in use while this test mode is used.
Thesettingcanbeconguredwiththefollowingparameter.
Menu path
Display Devicesetup►Diag/Service►Test►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►MTB►DeviceConguration►QueryDevice►MaintTBOriginal
Parameters(Part2)►Page4►Test►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
MTB 96 Test mode Test Mode Selects the test item.
From the table below, select the test terminal and process value.
Display:
Selection
Description
Display
F
OUNDATION
Fieldbus
O󰀨 O󰀨 Turnso󰀨thetestmode
Velocity test Velocity Startstestingtheowvelocity.
PO1 test Pulse Starts testing pulse output or frequency output 1 of the I/O2 terminal.
SO1 test Status Starts testing status output 1 of the I/O2 terminal.
Iftheowvelocityissetasatestvalue,thevolumetricowrateandcaloriecanbeobtainedfrom
the test value.
NOTE
Settheoutputfunctionofthepulse/statusterminal(I/O2)inSubsection5.14.1.Ifthesetoutput
functionisdi󰀨erentfromtheoutputfunctiontoperformtesting,thetestmodecannotbeused.
For example, if the I/O2 terminal is set as the frequency output, and the test output function is set
to the status output, the test cannot be started.
