<5. Functions>
68
IM 01E21A02-03EN
5.2.4 Operation of Totalizer Function at Alarm Occurrence
Theoperationofthetotalizercanbespeciedwhenanalarmthata󰀨ectsthetotalizationfunction
occurs.
Thesettingcanbeconguredwiththefollowingparameters.
Menu path
Display Devicesetup►Detailedsetup►Totalizer►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►STB►DeviceConguration►Conguration►Totalizer►(see
below)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 69 Totalizer1►Failureopts
Totalizer1►Total1Failure
Opts
Speciesthetotalizer1
operation to be performed
when an alarm occurs.
STB 78 Totalizer2►Failureopts
Totalizer2►Total2Failure
Opts
Speciesthetotalizer2
operation to be performed
when an alarm occurs.
From the table below, select the operation of the totalization function.
Selection
Description
Display
F
OUNDATION
Fieldbus
Measured value Measured value
Continues the totalization function with an instantaneous value at that
time even while an alarm is occurring.
Stop Stop
Displays the totalized value up to that point by immediately stopping the
totalizer if an alarm occurs.
Last valid Last valid
Continues the totalization function with the last instantaneous value
rightbeforeanalarmoccurs(monotonicalincreasing).
5.2.5 Start/Stop Setting for Totalization Function
The start/stop operation of the totalization function can be set.
Thesettingcanbeconguredwiththefollowingparameters.
Menu path
Display Devicesetup►Detailedsetup►Totalizer►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►STB►DeviceConguration►Conguration►Totalizer►(see
below)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 71 Totalizer1►Start/Stop Totalizer1►Total1Execution
SpeciesStart/Stoptothe
totalization function of totalizer
1.
STB 80 Totalizer2►Start/Stop Totalizer2►Total2Execution
SpeciesStart/Stoptothe
totalization function of totalizer
2.
NOTE
Thetotalizationfunctionissetto“Stop”atshipmentfromthemanufacturingfactory.Tostartthe
totalizationfunction,besuretosetthefunctionto“Start”.
