<6. Parameter Lists>
196
IM 01E21A02-03EN
6.4 Display Transducer Block
Relative
Index
Index
Parameter
Name
Default Value
Write
Mode
Description
0 2700 Block Header LTB O/S
Information on this block, such
as Block Tag, DD Revision,
Execution, etc.
1 2701 ST_REV 0 -
Represents the revision level of
the setting parameter of the own
block. This revision is updated if
the setpoint is changed. Used to
check for parameter change, etc.
2 2702 TAG_DESC
Space(32
characters)
AUTO
Universal parameter to store
a comment explaining tag
contents.
3 2703 STRATEGY 1 AUTO
Universal parameter intended to
be used for the high-level system
to separate function blocks.
4 2704 ALERT_KEY 1 AUTO
Keyinformationtoidentifywhere
an alert takes place. Generally,
this parameter is used by the
high-level system to identify
specicareasinaplantthat
areunderthecontrolofspecic
operators, to separate necessary
alerts only. This is one of the
universal parameters.
5 2705 MODE_BLK
0x08(Auto)
0x08(Auto)
0x88(Auto,O/S)
0x08(Auto)
AUTO
-
AUTO
AUTO
Universal parameter to show a
block operation state. Consists
of Actual mode, Target mode,
Permit mode and Normal mode.
6 2706 BLOCK_ERR 0x0000 -
Indicates the error statuses
related to the own block.
7 2707 UPDATE_EVT
0(Uninitialized)
0(Uninitialized)
0,0
0
0
AUTO
-
-
-
-
Indicates contents of the event
whenanupdateevent(achange
tothesetpoint)occurs.
8 2708 BLOCK_ALM
0(Uninitialized)
0(Uninitialized)
0,0
0(Other)
0
AUTO
-
-
-
-
Indicates contents of the alarm
when a block alarm occurs.
9 2709
TRANSDUCER_
DIRECTORY
1
2710
-
-
Parameter to store the index of
the transducer included in the
device.
10 2710
TRANSDUCER_
TYPE
32848(LCDTB) - Indicates the device type.
11 2711
TRANSDUCER_
TYPE_VER
0x0000 -
Indicates the version of the
device.
12 2712 XD_ERROR 0 -
Stores the most important
error among errors which
are occurring in the sensor
transducer block.
13 2713
COLLECTION_
DIRECTORY
0 -
Stores indexes of important
parameters in the transducer
block and the item ID of the
corresponding DD.
14 2714
DISP_LINE1_
SEL
1(PV) AUTO See 5.7.2.
15 2715
DISP_LINE2_
SEL
1(Flowrate(%)) AUTO See 5.7.2.
16 2716
DISP_LINE3_
SEL
12(PDTag) AUTO See 5.7.2.
To Next Page
