YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
55
IM 01E21A02-03EN
 Conductivity
Menu path
Display Devicesetup►Diag/Service►Diagnosis►Conductivity►Result►(seebelow)
F
OUNDATION
Fieldbus
ProcessVariables►DTB►ProcessVariables►DynamicVariables►DeviceVariables
►ConductivityValue►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
DTB 22
- Conductivity Value.Status
Displays the status of the
calculated conductivity.
Value Conductivity Value.Value
Displays the calculated
conductivity.
This parameter can be used only for AXG, not for AXW.
5.1.4 Engineering Unit Setting
TheunitoftheprocessvaluesetfortheAIchannel(see5.1.2)canbesetwiththefollowing
parameter.
Menu path
Display Devicesetup►Detailedsetup►Fieldbusinfo►AI1FB*►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►AI1*►DeviceConguration►Conguration►Scale►
TransducerScale►(seebelow)
*For AXG, one from Al1 to Al4, and for AXW, one from AI1 to AI3.
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
AI1 - AI4
(AXG)
AI1 - AI3
(AXW)
10
XD scale Units
index
Transducer Scale.Units Index
Speciestheunitofthe
process value selected in the
AI.
ThesettingsforthisparameterisalsoreectedtothefollowingparametersforSTB.
(OnlytheunitoftheprocessvalueselectedintheAIchannelisreected.)
 Flowvelocity,volumetricowrate,massowrate,calorie
Menu path
Display Devicesetup►Detailedsetup►Provar►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►STB►DeviceConguration►Conguration►Process
Variables►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 38 Velocity►Unit Velocity►VelocityUnit
Displays the physical unit of the
owvelocity.
STB 30 Volume►Unit
VolumeFlow►VolumeFlow
Unit
Displays the physical unit of the
volumetricowrate.
STB 34 Mass►Unit MassFlow►MassFlowUnit
Displays the physical unit of the
massowrate.
STB 42 Calorie►Unit Calorie►CaloricUnit
Displays the physical unit of the
calorie(onlyavailableforAXG,
notforAXW).
