YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
136
IM 01E21A02-03EN
NOTE
• Besuretousethevericationfunctionwhenthesensorisinthefullpipestate.Ifthesensoris
in the empty pipe state, the function to detect adhesion may not run normally.
• Whenusingthevericationfunction,correctlyspecifytheuidstatuswiththeparameter.
• Ifthereisaproblemwiththeresultofthevericationfunction,refertotheMaintenance
Manual.
5.9.7 Electrode Insulation Deterioration Diagnosis (only
available for AXG, not for AXW)
The electrode insulation deterioration diagnosis function diagnoses the deterioration of insulation
with the resistance value of the electrode and displays a warning if the deterioration of insulation
is detected. It takes approximately 5 minutes to complete this diagnosis.
For details about the alarm and warning, refer to Subsection 5.6.1.
Thesettingcanbeconguredwiththefollowingparameters.
Menu path
Display Devicesetup►Diag/Service►Diagnosis►(seebelow)
F
OUNDATION
Fieldbus
Diagnostic►DTB►DeviceDiagnostics►Diagnostics/Alerts►Diagnostics►(see
below)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
DTB 40 Diagnostic execute Diagnostic Exe
Speciestheexecution
of the electrode insulation
deterioration diagnostic
function.
*1
DTB 46 Diagnostic output Diagnostic Output
Speciestheoutputtoexecute
the electrode insulation
deterioration diagnostic
function.
*2
*1: Theelectrodeinsulationdeteriorationdiagnosiscanbeconguredwiththefollowingparameters.Inthecommunication
access of F
OUNDATION Fieldbus, the communication access is set with the procedure of the interactive operation guide
called DD Method.
Selection
Description
Display
F
OUNDATION
Fieldbus
Electrode insul exe Elec Ins exe
Startstheelectrodeinsulationdeteriorationdiagnosisfunction(only
availableforAXG,notforAXW).
*2: From the table below, select the output required to execute the diagnosis function.
Selection
Process value Totalizer Pulse output
Frequency
output
Display
F
OUNDATION
Fieldbus
Zero Zero 0% output
Input 0
(Outputxed)
0 pps 0% output
Measured value Measured value
Output of
calculated value
(Undened)
Totalization of
calculated value
(Undened)
Output of
calculated value
(Undened)
Output of
calculated value
(Undened)
Hold Hold
Fixes the last
valid value
before the
diagnosis starts.
Totalizes the
last valid value
before the
diagnosis starts.
Fixes the last
valid value
before the
diagnosis starts.
Fixes the last
valid value
before the
diagnosis starts.
