YOKOGAWA ADMAG TI Series

<5. Functions>
135
IM 01E21A02-03EN
*5: Selectthetargetfordiagnosisfromthetablebelow(Allofthemaresettodiagnosistargetatthetimeofshipment).
Selection
Description
Display
F
OUNDATION
Fieldbus
Magnetic circuit Magnetic Magnetic circuit diagnosis
Excitation circuit Excitation Excitation circuit diagnosis
Calculation circuit Calculation Calculation circuit diagnosis
Device status Device status Device alarm diagnosis
Connection status Conn status Wiring misconnection check
Inthedefaultstate,allofthediagnosisresultsarereectedinthenalresultsoftheverication.
Evenifsetwith“VFtargetselect”soasnottoreectthediagnosisresultstothenalresultsof
theverication,executiontimeforthevericationdoesnotchangebecausethediagnosisitselfis
executed.Inaddition,thediagnosisresultsselectedto“0”withVericationTargetaredisplayed
as“Skip”.
Notethatvericationitselfcannotbeexecutedifalldiagnosesareuncheckedinthecheckboxof
VericationTarget(0x0000).
The diagnosis result is displayed as shown below.
Display Devicesetup►Diag/Service►Verication►Result►(seebelow)
F
OUNDATION
Fieldbus
Diagnostic►DTB►DeviceDiagnostics►Diagnostics/Alerts►Maintenance►
Verication►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
DTB 51 Failed/Passed VF Check Results Execution result
DTB 52 VF operate time VF Operation Time
Operation time of
vericationwhen
started
DTB 53 Magnetic circuit Magnetic Circuit Res
Magnetic circuit
diagnosis result
DTB 54 Excite circuit Exciting Circuit Res
Excitation circuit
diagnosis result
DTB 55 Calc circuit Calc Circuit Res
Calculation circuit
diagnosis result
DTB 56 Device status Device Status Res
Device alarm
diagnosis result
DTB 57 Connect status Connection Status Res
Wiring connection
diagnosis result
The diagnosis result is judged as shown below.
Result
Description
Display
F
OUNDATION
Fieldbus
Passed Passed There are no problems concerning the diagnosis result.
Failed Failed There is a problem concerning the diagnosis result.
Canceled Canceled Cancels the diagnosis.
No data No Data Nodiagnosisresultdata(Thevericationfunctionisnotused.)
Unknown Unknown Cannot perform a diagnosis.
Skip Skip Outofvericationtarget
IMPORTANT
• Beforeusingthevericationfunction,besuretodisconnectthisproductfromthecontrolloop.
• Whilethevericationfunctionisused,thepulseoutputisnotoutputcorrectly.
• Notethatparameterscannotbechangedwhilethevericationfunctionisexecuted.
