YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
69
IM 01E21A02-03EN
5.2.6 Totalization Direction Setting
Thetotalizationdirectioncanbespeciedwhenusingthetotalizationfunction.
Thesettingcanbeconguredwiththefollowingparameters.
Menu path
Display Devicesetup►Detailedsetup►Totalizer►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►STB►DeviceConguration►Conguration►Totalizer►(see
below)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 70 Totalizer1►Options Totalizer1►Total1Options
Speciesthetotalization
direction of totalizer 1.
STB 79 Totalizer2►Options Totalizer2►Total2Options
Speciesthetotalization
direction of totalizer 2.
From the table below, select the totalization direction.
Selection
Description
Display
F
OUNDATION
Fieldbus
Balanced Balanced Totalizestheowrate(di󰀨erence)oftheforwardandreversedirections.
Absolute Absolute Totalizestheabsolutevalueoftheowrate.
Only positive OnlyPositive Totalizesonlytheowrateintheforwarddirection.
Only negative OnlyNegative Totalizesonlytheowrateinthereversedirection.
Hold Hold Stopstotalizationprocessing(holdingthecurrenttotalizedvalue).
5.2.7 Totalized Value Reset/Preset Function
Thereset/presetfunctioncanbespeciedforthetotalizedvalue.Iftheresetfunctionisused,
thefunctionresetsthetotalizedvalueto“0”.Ifthepresetfunctionisused,itsetsthepresetvalue
speciedinadvancetothetotalizedvalue.Thepresetfunctionisusedwhenstartingtocount
totalizationfromthespeciedvalue.
Thesettingcanbeconguredwiththefollowingparameters.
 Use of the reset/preset function
Menu path
Display Devicesetup►Detailedsetup►Totalizer►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►STB►DeviceConguration►Conguration►Totalizer►(see
below)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 72
Totalizer1►
Reset/Preset
Totalizer1►Total1Preset
Uses the reset/preset
function of totalizer 1.
STB 81
Totalizer2►
Reset/Preset
Totalizer2►Total2Preset
Uses the reset/preset
function of totalizer 2.
