YOKOGAWA ADMAG TI Series User Manual

<6. Parameter Lists>
217
IM 01E21A02-03EN
6.8 MAO Function Block (only AXG)
Relative
Index
Index
Parameter
Name
Default Value
Write
Mode
Description
0 10000 Block Header “MAO” O/S
Information on this block, such as Block
Tag, DD Revision, Execution, etc.
1 10001 ST_REV 0 -
Represents the revision level of the setting
parameter of the own block. This revision
is updated if the setpoint is changed. Used
to check for parameter change, etc.
2 10002 TAG_DESC
Space(32
characters)
AUTO
Universal parameter to store a comment
explaining tag contents.
3 10003 STRATEGY 1 AUTO
Universal parameter intended to be used
for the high-level system to separate
function blocks.
4 10004 ALERT_KEY 1 AUTO
Keyinformationtoidentifywhereanalert
takes place. Generally, this parameter is
used by the high-level system to identify
specicareasinaplantthatareunderthe
controlofspecicoperators,toseparate
necessary alerts only. This is one of the
universal parameters.
5 10005 MODE_BLK
0x80(O/S)
0x80(O/S)
0x88(Auto,O/S)
0x08(Auto)
AUTO
-
AUTO
AUTO
Universal parameter to show a block
operation state. Consists of Actual mode,
Target mode, Permit mode and Normal
mode.
6 10006 BLOCK_ERR 0x0000 -
Indicates the error statuses related to the
own block.
7 10007 CHANNEL
20(Temperature) O/S
Parameter to select a channel for the
transducer block to connect with. For this
product,20xed.
8 10008 IN_1
0x0B
0
AUTO
AUTO
See 5.4.
9 10009 IN_2
0x0B
0
AUTO
AUTO
Not used for this product.
10 10010 IN_3
0x0B
0
AUTO
AUTO
11 10011 IN_4
0x0B
0
AUTO
AUTO
12 10012 IN_5
0x0B
0
AUTO
AUTO
13 10013 IN_6
0x0B
0
AUTO
AUTO
14 10014 IN_7
0x0B
0
AUTO
AUTO
15 10015 IN_8
0x0B
0
AUTO
AUTO
16 10016 MO_OPTS 0x0000 AUTO
Operational parameter to specify the
output operation of MAO Function Block.
Speciesavaluetobetransmittedtothe
sensor transducer block mainly at the fault
state. Bit assignment complies with the
Communicationstandardspecications.
17 10017
FSTATE_
TIME
0 AUTO
Transits to the fault state when an input
continues to be Bad for more than time set
by FSTATE_TIME.
18 10018
FSTATE_
VAL1
0 AUTO
Value to be transmitted to the sensor
transducer block as input 1 at the fault
state.(Option)
19 10019
FSTATE_
VAL2
0 AUTO
Value to be transmitted to the sensor
transducer block as input 2 at the fault
state.(Option)
