YOKOGAWA ADMAG TI Series User Manual

<Appendix 1. Application, Setting And Change Of Basic Parameters>
237
IM 01E21A02-03EN
A1.2 Setting and Change of Basic Parameters
This section describes procedures to set and change the parameters for each block. Obtaining
accesstoeachparameterdi󰀨ersdependingonthecongurationsystemused.Fordetails,refer
totheinstructionmanualforeachcongurationsystem.
(1)Accesstheblockmode(MODE_BLK)ofeachblock.
(2)Settheblockmode(MODE_BLK)target
(note1)
to Auto, Man or O/S
(note2)
in accordance with
the Write Mode of the parameter to be set or changed.
(3)Accesstheparametertosetorchange.
(4)Makesettingorchangeinaccordancewitheachparameter.
(5)SettheTargetofblockmode(MODE_BLK)toAuto
(note2)
.
IMPORTANT
Do not turn the power OFF immediately after setting parameters. To improve the reliability of the
device, processing to store data to EEPROM is duplexing. If the power is turned OFF within 30
seconds after setting of parameters, changed parameters are not saved and may return to their
original values.
Note 1: Block mode consists of the following four modes that are controlled by the universal parameter
that displays the operating condition of each block.
 Target(targetmode) : Setstheoperatingconditionoftheblock.
 Actual(actualmode) : Indicatesthecurrentblockoperatingcondition.
 Permit(permitmode) : Indicatestheoperatingconditionthattheblockisallowedtotake.
 Normal(normalmode): Indicatetheoperatingconditionthattheblockwillusuallytake.
Note 2: The operating conditions which the individual blocks can take are as shown below for each block.
AI Function
Block
IT Function
Block
DI Function
Block
AR
Function
Block
PID
Function
Block
Transducer
Block
Resource
Block
Automatic(Auto) ◦ ◦ ◦ ◦ ◦ ◦ ◦
Manual(Man) ◦ ◦ ◦ ◦ ◦
OutofService(O/S) ◦ ◦ ◦ ◦ ◦ ◦ ◦
NOTE
For various setting changes, there is a mode which allows each parameter to be written.
If a parameter cannot be rewritten, check for write mode columns in parameter lists in Chapter 6.
