YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
56
IM 01E21A02-03EN
Display Devicesetup►Detailedsetup►Totalizer►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►STB►DeviceConguration►Conguration►Totalizer►(see
below)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 67 Totalizer1►Unit Totalizer1►Total1Lowcut Displays the unit of totalizer 1.
STB 76 Totalizer2►Unit Totalizer2►Total2Lowcut Displays the unit of totalizer 2.
NOTE
If there is inconsistency between the process value selected in the AI FB channel and the unit set
with XD scale Units index, Bit1 in Block Error of the AI function block is set on.
Example:
AIChannel:2(volumetricowrate),XDscaleUnitsindex(TransducerScale.UnitsIndex):1328
(t/h)
5.1.5 Span Setting
Theowvelocity,volumetricowrate,massowrate,andcaloriecanbesetfromSensorTB.
However, the unit of the span is the unit set in Subsection 5.1.4.
Iftheowrateunitischanged,thespanvalueisconvertedinconjunctionwiththechangedunit.
Thesettingcanbeconguredwiththefollowingparameters.
 Flowvelocity,volumetricowrate,massowrate,calorie
Menu path
Display Devicesetup►Detailedsetup►Provar►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►STB►DeviceConguration►Conguration►Process
Variables►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 62 Velocity►Span Velocity►VelocitySpan
Speciesthespanoftheow
velocity.
STB 63 Volume►Span
VolumeFlow►VolumeFlow
Span
Speciesthespanof
volumetricowrate.
STB 64 Mass►Span MassFlow►MassFlowSpan
Speciesthespanofthemass
owrate.
STB 65 Calorie►Span Calorie►CaloricSpan
Speciesthespanofthe
calorie.
(OnlyavailableforAXG,notfor
AXW).
