YOKOGAWA ADMAG TI Series User Manual

<6. Parameter Lists>
210
IM 01E21A02-03EN
6.6 AI Function Block
Relative
Index
Index
Parameter
Name
Default Value
Write
Mode
Description
AI1 AI2 AI3
AI4
(only
AXG)
0 4000 4100 4200 4300 Block Header
AI1:“AI1”
AI2:“AI2”
AI3:“AI3”
AI4:“AI4”
O/S
Information on this block, such
as Block Tag, DD Revision,
Execution, etc.
1 4001 4101 4201 4301 ST_REV 0 -
Represents the revision level
of the setting parameter of
the own block. This revision
is updated if the setpoint is
changed. Used to check for
parameter change, etc.
2 4002 4102 4202 4302 TAG_DESC Space(32characters) AUTO
Universal parameter to store
a comment explaining tag
contents.
3 4003 4103 4203 4303 STRATEGY 1 AUTO
Universal parameter intended
to be used for the high-level
system to separate function
blocks.
4 4004 4104 4204 4304 ALERT_KEY 1 AUTO
Keyinformationtoidentify
where an alert takes place.
Generally, this parameter is
used by the high-level system
toidentifyspecicareasin
a plant that are under the
controlofspecicoperators,to
separate necessary alerts only.
This is one of the universal
parameters.
5 4005 4105 4205 4305 MODE_BLK
0x08(Auto)
0x08(Auto)
0x88(Auto,O/S)
0x08(Auto)
AUTO
-
AUTO
AUTO
Universal parameter to show a
block operation state. Consists
of Actual mode, Target mode,
Permit mode and Normal
mode.
6 4006 4106 4206 4306 BLOCK_ERR 0x0000 -
Indicates the error statuses
related to the own block.
7 4007 4107 4207 4307 PV
0x1C
0.0
-
-
IndicatesthePVvalue(orthe
process value corresponding
tothevalue)andstatustobe
used for functional execution.
8 4008 4108 4208 4308 OUT
0x1C
0.0
-
MAN
Indicates the value and status
of analog output. Held when the
block mode is MAN and O/S.
9 4009 4109 4209 4309 SIMULATE
0
0.0
0
0.0
1
AUTO
AUTO
-
-
AUTO
Parameter to simulate the AI
block. The user can arbitrarily
specify an input value and
status from CHANNEL.
10 4010 4110 4210 4310 XD_SCALE
AI1 : 28.2743
AI2,AI3,AI4 : 1
0.0
AI1:1349(m
3
/h)
AI2, AI3, AI4 :
1034(m
3
)
4
O/S
O/S
O/S
O/S
Setsaninputvalue(measured
range)fromtheTransducer
Block which corresponds to 0%
and 100% points in calculation
in the AI function block.
11 4011 4111 4211 4311 OUT_SCALE
AI1 : 28.2743
AI2,AI3,AI4 : 1
0.0
AI1:1349(m
3
/h)
AI2,AI3,AI4:1034(m
3
)
4
O/S
O/S
O/S
O/S
Parameter to scale output. Sets
the output values for 0% and
100% points in calculation in
the AI function block. Any unit
stipulated in the FieldComm
Groupspecicationscanbe
dened.
