YOKOGAWA ADMAG TI Series User Manual

<6. Parameter Lists>
211
IM 01E21A02-03EN
Relative
Index
Index
Parameter
Name
Default Value
Write
Mode
Description
AI1 AI2 AI3
AI4
(only
AXG)
12 4012 4112 4212 4312 GRANT_DENY
0x00
0x00
AUTO
AUTO
The parameter for checking
if various operations have
been executed. Set a bit
corresponding to the GRANT
parameter before various
operations are executed.
Check the DENY parameter
after the operation. If the
bit for the operation is not
set, it indicates that the
operation was executed. Bit
assignment complies with
the Communication standard
specications.
13 4013 4113 4213 4313 IO_OPTS 0x0000 O/S
Speciestheoption
settings and input/output
functions of the IO block. Bit
assignment complies with
the Communication standard
specications.
14 4014 4114 4214 4314 STATUS_OPTS 0x0000 O/S
Option for the user to select
in the status book processing.
Bit assignment complies with
the Communication standard
specications.
15 4015 4115 4215 4315 CHANNEL
AI1:2(Volumeow)
AI2,AI3,AI4:5(Total1)
O/S
Parameter to select a channel
for the transducer block to
connect with.
16 4016 4116 4216 4316 L_TYPE 1(Direct) Man
Parameter to select a
totalization method for OUT.
Refer to A1.3 for selection.
17 4017 4117 4217 4317 LOW_CUT 0.0 AUTO
Speciesalow-cutpoint.
When the square root output
is selected, and this function is
set to valid with IO_OPTS, the
output becomes 0 if the output
goes below the setpoint for this
parameter.
18 4018 4118 4218 4318 PV_FTIME 3.0 AUTO
SpeciestheAIblocklter
(damping)inseconds.
19 4019 4119 4219 4319 FIELD_VAL
0x00
0.0
-
-
Value obtained by scaling the
input value with XD_SCALE
and expressed in %. Raw value
thatisnotinuencedbythe
calculationorlterspeciedby
L_TYPE.
20 4020 4120 4220 4320 UPDATE_EVT
0(Uninitialized)
0(Uninitialized)
0,0
0
0
AUTO
-
-
-
-
Indicates contents of the event
whenanupdateevent(a
changetothesetpoint)occurs.
21 4021 4121 4221 4321 BLOCK_ALM
0(Uninitialized)
0(Uninitialized)
0,0
0(Other)
0
AUTO
-
-
-
-
Indicates contents of the alarm
when a block alarm occurs.
22 4022 4122 4222 4322 ALARM_SUM
0x0000
0x0000
0x0000
0x0000
-
-
-
AUTO
Parameter to indicate the alarm
status of the entire block.
