YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
154
IM 01E21A02-03EN
Alarm Name
Restore or
Duplicate
Display F
OUNDATION Fieldbus
393:PID LL Alarm 393:PID Low Low Alarm

394:PID Hi Alarm 394:PID High Alarm

395:PID Lo Alarm 395:PID Low Alarm

395:PID Lo Alarm PID Low Alarm

IMPORTANT
Whenusingtherestorefunction,besuretoprepareabackupleinthebuilt-inmemoryorthe
microSDcard.Notethattherestorefunctionisnotexecutableifabackupleisnotprovided.
When executing the restore function from the microSD card, make sure that the preparation of
the microSD card is completed. Approximately one minute is required until the microSD card can
be used after it has been turned on.
5.11.3 Backup and Restore Parameters
The list below shows the parameters that can be backed up or restored.
NOTE
Those parameters not listed in the following table are out of scope for both back up and restore.
(VelocityUnit,VolumeFlowUnit,MassFlowUnit,Total1Unit,etc.)
Those parameters which can be backed up have check marks in the check box in the column of
“Duplicatedata”inthefollowingtable.
Block
Name
Parameter Restore
Display F
OUNDATION Fieldbus
Duplicate
data
Restore
data
Compulsion
data
Restore
Factory
STB Damp AO/F Velocity Damping
 
-

STB Damp pls/ttl Velocity Damping Ttl
 
-

STB Damp AO/F Volume Flow Damping
 
-

STB Damp pls/ttl Vol F Damping Total
 
-

STB Damp AO/F Mass Flow Damping
 
-

STB Damp pls/ttl Mass F Damping Total
 
-

STB Damp AO/F CaloricDamping
 
-

STB Damp pls/ttl CaloricDampingTtl
 
-

STB Low MF Low MF
   
STB High MF High MF
   
STB Low MF EDF Low MF EDF
 
-

STB High MF EDF High MF EDF
 
-

STB Flow sensor sel Select Flow Sensor
 
-

STB Measure mode Measure Mode
 
-

STB Nominal size unit Nominal Size Unit
   
STB Nominal size Nominal Size
   
STB PVowselect Selected Flow
   
STB Span Velocity Span
   
STB Span Volume Flow Span
   
STB Span Mass Flow Span
   
STB Span Calorie Span
 
-

STB Zero value Zero Value
 
-

STB Low cut Total1 Lowcut
 
-

STB Failure opts Total1 Failure Option
 
-

STB Options Total1 Options
 
-

