<5. Functions>
50
IM 01E21A02-03EN
5.1 Basic Settings
5.1.1 Overview
Thisproductcanmeasuretheowvelocity,volumetricowrate,massowrate,calorie,and
various diagnostic values.
Refertothetablebelowforthespecicationcodesforcommunication/input-outputand
connection terminals, and input and output for each terminal.
Communication
and I/O
code
Connection Terminal
I/O1 +/- I/O2 +/- I/O3 +/- I/O4 +/-
F0 -F
F
OUNDATION
Fieldbus
communication
P/Sout
(Passive)
- -
P/Sout: Pulse output or status output
The position of Communication and I/O code:
 IntegralType:AXG□□□-□□□□□□□□□□□□□□-□■■□□
  AXW□□□-□□□□□□□□□□□□□□-□■■□□
  AXW□□□G-■□□□□□-□□□□-□□□
 Remotetransmitter:AXG4A-□□□□□□□■■□□
  AXW4A-□□□□□□□■■□□
5.1.2 Connection of Process Value to AI Function
TheprocessvaluecalculatedbySTBandDTBareoutputtoaspecicchannel,respectively.By
selecting the channel used in the AI function block, a process value is obtained from STB and
DTB.
The relation of the channel for each process value and the channel which can be selected from
eachAIfunctionblockisshowninthegurebelow.
To Next Page
