<5. Functions>
138
IM 01E21A02-03EN
Selection
Description
Display
F
OUNDATION
Fieldbus
Disable Disable Doesnotusetheownoisediagnosisfunction.
Enable Enable Usestheownoisediagnosisfunction.
NOTE
Iftheownoisediagnosisfunctionissetto“Disable”,theownoisevalueandlevelarecleared.
5.9.9 Diagnosing Low Conductivity (only available for AXG,
not for AXW)
The low conductivity diagnosis function calculates conductivity from the resistance value and size
oftheelectrodeanddisplaysawarningiftheconductivityfallsbelowthespeciedvalue.
For details about the alarm and warning, refer to Subsection 5.6.1. Also, for the conductivity
value, refer to Subsection 5.1.3.
Thesettingcanbeconguredwiththefollowingparameters.
Menu path
Display Devicesetup►Diag/Service►Diagnosis►Conductivity►(seebelow)
F
OUNDATION
Fieldbus
Diagnostic►DTB►DeviceDiagnostics►Diagnostics/Alerts►Diagnostics►
Conductivity►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
DTB 38 Function Low Conduct Check
Speciestheuseofthe
low conductivity diagnosis
function.
*1
DTB 39 Low limit Conductivity Limit
Speciesthevalueusedto
judge the low conductivity.
Menu path
Display Devicesetup►Detailedsetup►Deviceinfo►Orderinfo►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►MTB►DeviceConguration►DeviceInformation►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
MTB 48 Electrode size Electrode Size Displays the electrode size.
*1: From the table below, select the use of the low conductivity diagnosis function.
Selection
Description
Display
F
OUNDATION
Fieldbus
Disable Disable Does not use the low conductivity diagnosis function.
Enable Enable Uses the low conductivity diagnosis function.
