YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
142
IM 01E21A02-03EN
5.10.2 Test Value Setting
Itisnecessarytosetatestvaluefortheterminaloutputvalue(pulse/status)andtheprocess
value.
Thesettingcanbeconguredwiththefollowingparameters.
However,theunitoftheprocessvaluetotestistheunitspeciedinSubsection5.1.4.Iftheunitis
changed, the process value is also changed in conjunction with the changed unit.
Menu path
Display Devicesetup►Diag/Service►Test►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►MTB►DeviceConguration►QueryDevice►MaintTBOriginal
Parameters(Part2)►Page4►Test►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
MTB 97 Velocity Velocity Test Value
Setsthedisplayitemtotheow
velocity.
MTB 98 PO1 P1 Test Value
Speciesthefrequencyof
pulse output or frequency
output 1 for the I/O2 terminal.
MTB 99 SO1 SO1 Test Value
Speciesthestatusofstatus
output 1 for the I/O2 terminal.
5.10.3 Test 2 Mode
Test 2 Mode is the function to perform a test to the process value, analog output, totalized value
and pulse at once.
The test value can be set in the range between -10.0% and 110.0%.
Inputtestvalues(%)aretestedwithascalevalueinresponsetothespanofeachprocessvalue.
Menu path
Display Devicesetup►Diag/Service►Test►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►MTB►DeviceConguration►QueryDevice►MaintTBOriginal
Parameters(Part2)►Page4►Test►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
MTB 100 Test 2 mode Test 2 Mode Setting Test 2 mode
MTB 101 Test 2 value Test 2 Output Value Setting Test 2 mode value
From the table below, select the setting for Test 2 mode.
Selection
Display F
OUNDATION Fieldbus
Normal Normal
Test Test
