<5. Functions>
164
IM 01E21A02-03EN
5.14 Pulse Output, Frequency Output, and Status
Output
NOTE
The pulse output, frequency output and status output should be used only at calibrating, and not
used when normally running.
5.14.1 Outputs of I/O2 Terminals
Use the I/O2 terminal only when calibrating. The I/ O2 terminal can be used as the pulse output,
frequency output, and status output.
Thesettingcanbeconguredwiththefollowingparameters.
Menu path
Display Devicesetup►Detailedsetup►Pulse/Statusout►PO1/SO1►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►MTB►DeviceConguration►Maintenance►Pulse/StatusOut
►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
MTB 102 Output mode Pulse 1 Output Mode
SpeciestheoutputoftheI/O2
terminal.
From the table below, select the output of I/O2 terminal.
Selection
Description
Display
F
OUNDATION
Fieldbus
No function No function Does not use the terminal.
Fixed pulse output Fixed Pulse Output Setstothexedpulseoutput.
Frequency output Frequency Output Setstothefrequencyoutput(Duty50%).
Status output Status Output
Sets to the status output.
For details about the status output, refer to Subsection 5.14.6.
5.14.2 Alarm Output Function
The alarm output function can be used when using the frequency output or pulse output. This
function can be set the output operation to be performed when an alarm has activated.
Thesettingcanbeconguredwiththefollowingparameter.
Menu path
Display Devicesetup►Detailedsetup►Pulse/Statusout►PO1/SO1►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►MTB►DeviceConguration►Maintenance►Pulse/StatusOut
►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
MTB 109 Alarm out Pulse 1 Alarm Out
Speciesthealarmoutput
function for the frequency
output or pulse output.
To Next Page
