YOKOGAWA ADMAG TI Series

<5. Functions>
163
IM 01E21A02-03EN
F0520.ai
H
L
1 2
ON
OFF
SW1
Safety cover
Simulation switch
(SW1-1)
Write lock switch
(SW1-2)
Figure 13.1 Settings of Simulation Switch
IMPORTANT
• To set the simulation switch, it needs to remove and install the cover on the display side.
Refer to the procedures described on the ADMAG TI Installation Manual for implementation.
• To secure your safety, do not touch an electric circuit and cable other than the simulation
switch.
