<4.Conguration>
46
IM 01E21A02-03EN
Table 4.22 Indexes of VIEW for Each Block
Block Name
VIEW
1 2 3 4
Resource block 40100 40101 40102 40103
Sensor transducer block 40200 40201 40202 to 40203 40204 to 40209
Diagnosis transducer block 40250 40251 40252 to 40253 40254 to 40255
Display transducer block 40270 40271 40272 40273 to 40274
Maintenance transducer block 40290 40291
40292 to
40299*
40300 to
40309*
AI1 function block 40400 40401 40402 40403
AI2 function block 40410 40411 40412 40413
AI3 function block 40420 40421 40422 40423
AI4 function block 40430 40431 40432 40433
DI1 function block 40600 40601 40602 40603
DI2 function block 40610 40611 40612 40613
DI3 function block 40620 40621 40622 40623
PID function block 40800 40801 40802 40803
MAO function block 41000 41001 41002 41003
IT1 function block 41600 41601 41602 41603
IT2 function block 41610 41611 41612 41613
AR function block 41750 41751 41752 41753
*: Includes the VIEW object for manufacturing.
4.6.5 Function Block Parameters
Function block parameters can be read or set from the host. For the list of the parameters of the
Resource block, Transducer block, AI block, DI block and MAO block, refer to “PARAMETER
LISTS”inChapter6.FordetailsaboutfunctionblocksotherthantheAI,DIandMAOblocks,the
LM function, and the software download function, refer to Appendices 1 to 6.
