YOKOGAWA ADMAG TI Series

  <4.Conguration>
45
IM 01E21A02-03EN
Table 4.20 View Object for IT Function Block
Relative
Index
Parameter Name
View
1 2 3 4
1 ST_REV 2 2 2 2
2 TAG_DESC
3 STRATEGY 2
4 ALERT_KEY 1
5 MODE_BLK 4 4
6 BLOCK_ERR 2 2
7 TOTAL_SP 4 4
8 OUT 5 5
9 OUT_RANGE 11
10 GRANT_DENY 2
11 STATUS_OPTS 2
12 IN_1 5 5
13 IN_2 5 5
14 OUT_TRIP 2 2
15 OUT_PTRIP 2 2
16 TIME_UNIT1 1
17 TIME_UNIT2 1
18 UNIT_CONV 4
19 PULSE_VAL1 4
20 PULSE_VAL2 4
21 REV_FLOW1 2 2
22 REV_FLOW2 2 2
23 RESET_IN 2 2
24 STOTAL 4
25 RTOTAL 4 4
26 SRTOTAL 4
27 SSP 4
28 INTEG_TYPE 1
29 INTEG_OPTS 2
30 CLOCK_PER 4
31 PRE_TRIP 4
32 N_RESET 4 4
33 PCT_INCL 4 4
34 GOOD_LIM 4
35 UNCERT_LIM 4
36 OP_CMD_INT 1 1
37 OUTAGE_LIM 4
38 RESET_CONFIRM 2 2
39 UPDATE_EVT
40 BLOCK_ALM
Total 52 17 64 42
Table 4.21 View Object for AR Function Block
Relative
Index
Parameter Name
View
1 2 3 4
1 ST_REV 2 2 2 2
2 TAG_DESC
3 STRATEGY 2
4 ALERT_KEY 1
5 MODE_BLK 4 4
6 BLOCK_ERR 2 2
7 PV 5 5
8 OUT 5 5
9 PRE_OUT 5 5
10 PV_SCALE 11
11 OUT_RANGE 11
12 GRANT_DENY 2
13 INPUT_OPTS 2
14 IN 5
15 IN_LO 5
16 IN_1 5
17 IN_2 5
18 IN_3 5
19 RANGE_HI 4
20 RANGE_LO 4
21 BIAS_IN_1 4
22 GAIN_IN_1 4
23 BIAS_IN_2 4
24 GAIN_IN_2 4
25 BIAS_IN_3 4
26 GAIN_IN_3 4
27 COMP_HI_LIM 4
28 COMP_LO_LIM 4
29 ARITH_TYPE 1
30 BAL_TIME 4
31 BIAS 4
32 GAIN 4
33 OUT_HI_LIM 4
34 OUT_LO_LIM 4
35 UPDATE_EVT
36 BLOCK_ALM
Total 23 26 48 68
