YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
115
IM 01E21A02-03EN
Selection
Description
Display
F
OUNDATION
Fieldbus
7 digit 7 digit Fixesthenumberofdecimalplacesto“7”.
5.7.4 Display Line Count and Scroll Settings
This product can show up to eight items on the display by scrolling, with four lines max. shown
at a time. The scroll method can be selected from the automatic display switching or the display
switching using the IR switch.
Thesettingcanbeconguredwiththefollowingparameters.
Menu path
Display Devicesetup►Detailedsetup►Displayset►Optionalcong►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►LTB►DeviceConguration►Conguration►DisplayOperation
Conguration►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
LTB 27 Line mode Display Line
Speciesthenumberoflinestobe
shown on the display.
*1
LTB 31 Scroll mode Display Scroll
Speciesthedisplayscroll
method.
*2
*1: From the table below, select the number of display lines.
The font size is automatically adjusted based on the number of the displayed line.
Selection
Description
Display
F
OUNDATION
Fieldbus
1line(big) 1Line(Big) 1-line display without unit.
The numeric value is displayed in a large font.
1 line 1 Line 1-line display with unit.
2 line 2 Line 2-line display with units.
