<5. Functions>
119
IM 01E21A02-03EN
5.7.6 Other Settings
(1) Display contrast (graduations) setting
Thecontrastofthedisplaycanbechangedto11levels(+5to-5).
Thesettingcanbeconguredwiththefollowingparameter.
Menu path
Display Devicesetup►Detailedsetup►Displayset►Optionalcong►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►LTB►DeviceConguration►Conguration►DisplayOperation
Conguration►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
LTB 26 Contrast Display Contrast
Speciesthecontrastofthe
display.
+5 +4 +3 +2 +1 0 -1 -2 -3 -4 -5
NOTE
How the contrast of the display looks changes a little depending on ambient temperature.
Set the contrast of the display by taking into account the ambient temperature of the environment
where the display is used.
(2) Display damping time constant setting
This function can specify the damping time constant for the display independently of that
speciedinSubsection5.1.6.
Thesettingcanbeconguredwiththefollowingparameters.
Menu path
Display Devicesetup►Detailedsetup►Displayset►Optionalcong►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►LTB►DeviceConguration►Conguration►DisplayOperation
Conguration►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
LTB 32 Damp Display Damping
Speciesthedampingtime
constant of the display.
NOTE
Thedampingtimeconstantofthedisplayise󰀨ectiveonlyforthedisplay.RefertoSubsection
5.1.6. to specify the damping time constant for the output of the physical quantity.
NOTE
The damping time constant of the display is not applied to the following display item.
AI1Flowrate,AI1Flowrate(%),AI1Flowrate(%Bar),AI1.OUT,AI2.OUT,AI3.OUT,AI4.OUT,IT1.
OUT, IT2.OUT, AR.OUT
For details about the display item, refer to Subsection 5.7.2.
