YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
144
IM 01E21A02-03EN
5.11 Event Management Function
5.11.1 Storing Parameter (Backup)
Thebackupfunctioncanstoreparametersettingsinthedisplay’sbuilt-inmemory(display
board)ormicroSDcard(withtheoptionalcodeMCselected).Ifthebackupdataisrestored,the
parameter settings can be duplicated to another product. The display’s built-in memory can store
data for three backups and the microSD card can store as much data as the capacity allows.
There are three backup methods available: Backup from the main board of this product to the
memory on the display board, backup from the main board of the product to the microSD card,
andbackupfromthememoryonthedisplayboardtothemicroSDcard.Thelename,backup
name,anddatecanbespeciedusingthebackupfunction.
ThedatabackeduptothemicroSDcardisstoredinthe“YOKOGAWA”folderasa“.PAR”le.
Thesettingcanbeconguredwiththefollowingparameters.
For details about the backup parameters, refer to Subsection 5.11.3.
Menu path
Display Devicesetup►Diag/Service►Parambkup/restore►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►MTB►DeviceConguration►Maintenance►Parameter
Backup/Restore►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
MTB 72 F backup name Factory Backup Name
Displaysthebackupnamedened
at shipment from the manufacturing
factory.
MTB 73 F backup date Factory Backup Date
Displays the backup date at
shipment from the manufacturing
factory.
MTB 74 SD backup name SD Backup Name
Speciesthenameoftheletobe
backed up to the microSD card.
MTB 75 Backup name 1 Backup Name 1
Speciesbackupname1.
Up to 16 characters
MTB 76 Backup date 1 Backup Date 1 Speciesdate1.
MTB 77 Backup name 2 Backup Name 2
Speciesbackupname2.
Up to 16 characters
MTB 78 Backup date 2 Backup Date 2 Speciesdate2.
MTB 79 Backup name 3 Backup Name 3
Speciesbackupname3.
Up to 16 characters
MTB 80 Backup date 3 Backup Date 3 Speciesdate3.
MTB 81 Backup execute Backup Execute
Speciestheexecutionofthe
backup function.
*1
MTB 82 Backup result Backup Result
Displays the result of the backup
function.
*2
