<5. Functions>
145
IM 01E21A02-03EN
*1: From the table below, select the execution of the backup function. In the communication access of FOUNDATION
Fieldbus, the communication access is set with the procedures of the interactive operation guide called DD Method.
Selection
Description
Display
F
OUNDATION
Fieldbus
Not execute Not Execute Does not back up data.
Store main to 1 Store Main to 1
Backs up parameter settings from the main board to memory 1 in the
display’s built-in memory.
Store main to 2 Store Main to 2
Backs up parameter settings from the main board to memory 2 in the
display’s built-in memory.
Store main to 3 Store Main to 3
Backs up parameter settings from the main board to memory 3 in the
display’s built-in memory.
Store main to SD Store Main to SD Backs up parameter settings from the main board to the microSD card.
Store EEP1 to SD Store EEP1 to SD
Backs up parameter settings from memory 1 in the display’s built-in
memory to the microSD card.
Store EEP2 to SD Store EEP2 to SD
Backs up parameter settings from memory 2 in the display’s built-in
memory to the microSD card.
Store EEP3 to SD Store EEP3 to SD
Backs up parameter settings from memory 3 in the display’s built-in
memory to the microSD card.
*2: The result of the backup function is displayed as shown below.
Selection
Description
Display
F
OUNDATION
Fieldbus
Unexecuted Unexecuted Backup not executed.
Success Success Backup successful.
Failure Failure Backup failed.
Running Running Parameter backup running.
To Next Page
