<5. Functions>
146
IM 01E21A02-03EN
The table below shows alarms whose parameters can be backed up when an alarm occurs.
: Executable when an alarm occurs.
-: Not executable when an alarm occurs.
Alarm name
Backup
Display F
OUNDATION Fieldbus
010:Main CPU FAIL 10:Main board CPU failure -
011:Rev calc FAIL 11:Reverse calculation failure -
012:Main EEP FAIL 12:Main board EEPROM failure -
013:MainEEPdt 13:Main board EEPROM default -
014:Snsr bd FAIL 14:Sensor board failure

015:Snsr comm ERR 15:Sensor communication error

016:AD1FAIL[Sig] 16:A/D1failure[Signal]

017:AD2FAIL[Excit] 17:A/D2failure[Exciter]

018:Coil open 18:Coil open

019:Coil short 19:Coil short

020:Exciter FAIL 20:Exciter failure

027:Restore FAIL 27:Parameter restore incomplete

028:Ind bd FAIL 28:Indicator board failure -
029:Ind bd EEP FAIL 29:Indicator board EEP failure -
030:LCD drv FAIL 30:LCD driver failure -
031:Ind bd mismatch 31:Indicator board mismatch -
032:Ind comm ERR 32:Indicator communication error -
033:microSD FAIL 33:microSD failure -
050:Signaloverow 50:Signaloverow

051:Empty detect 51:Empty pipe detection

053:Adh over lv 4 53:Adhension over level 4

060:Span cfg ERR 60:Spancongurationerror -
066:Density cfg ERR 66:Densitycongurationerror -
067:Pls 1 cfg ERR 67:Pulse output 1 cfg error -
069:Nomi size cfg 69:Nominal size cfg error -
070:Adh cfg ERR 70:Adhesioncongurationerror -
071:FLN cfg ERR 71:Flow noise cfg error -
072:Log not start 72:Data logging not started -
082:Pls 1 saturate 82:Pulse output 1 saturated

085:Cable miscon 85:Cable misconnect

086:Coil insulation 86:Coil insulation warning

087:Adhesion lv 3 87:Adhesion over level 3

088:LC warn 88:Low conductivity Warning

089:Insu detect 89:Insulation detection

090:FLN over lv 3 90:Flow noise over level 3

091:FLN over lv 4 91:Flow noise over level 4

092:AZ warn 92:Autozero warning

093:Verif warn 93:Vericationwarning

094:Fact noise warn 94:Factory noise warning

095:Simulate active 95:Simulation active

098:Pls1x 98:Pulseoutput1xed

101:Param restore run 101:Parameter restore running -
102:Disp over 102:Display over warning -
103:SD size warn 103:microSD card size warning -
104:Bkup incmplt 104:Parameter backup incomplete

105:SD mismatch 105:microSD card mismatch -
106:SD removal ERR 106:microSD card removal error -
120:Watchdog 120:Watchdog

121:Powero󰀨 121:Powero󰀨

122:Inst power FAIL 122:Instant power failure

123:Param bkup run 123:Parameter backup running -
