YOKOGAWA ADMAG TI Series

<5. Functions>
70
IM 01E21A02-03EN
From the table below, select the reset/preset function. In the communication access of
F
OUNDATION Fieldbus, the communication access is set with the procedures of the interactive
operation guide called DD Method.
Selection
Description
Display
F
OUNDATION
Fieldbus
Not execute Not execute Does not use the reset/preset function of the totalized value.
Reset Reset Uses the reset function of the totalized value.
Preset Preset Uses the preset function for the totalized value.
 Preset value setting
Menu path
Display Devicesetup►Detailedsetup►Totalizer►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►STB►DeviceConguration►Conguration►Totalizer►(see
below)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 73
Totalizer1►
Preset value
Totalizer1►Total1Preset
Value
Speciesthepresetvalueof
totalizer 1.
STB 82
Totalizer2►
Preset value
Totalizer2►Total2Preset
Value
Speciesthepresetvalueof
totalizer 2.
NOTE
Theparameterreturnsto“Notexecute”afterthetotalizationvaluereset/presetfunctionhasbeen
used.
