<5. Functions>
80
IM 01E21A02-03EN
CHANNEL
number
Channel Selection
Model
Display F
OUNDATION Fieldbus
25 Mass1 Hi/Lo Limit MasFlw.1 AXG / AXW
26 Mass2 Hi/Lo Limit MasFlw.2 AXG / AXW
27 Calorie1 Hi/Lo Limit Calo.1 AXG
28 Calorie2 Hi/Lo Limit Calo.2 AXG
29 Adhesion1 Hi/Lo Limit Adh.1 AXG / AXW
30 Adhesion2 Hi/Lo Limit Adh.2 AXG / AXW
31 Elec.A1 Hi/Lo Limit Elec.A1 AXG / AXW
32 Elec.A2 Hi/Lo Limit Elec.A2 AXG / AXW
33 Elec.B1 Hi/Lo Limit Elec.B1 AXG / AXW
34 Elec.A2 Hi/Lo Limit Elec.B2 AXG / AXW
35 Flow Noise1 Hi/Lo Limit FLN.1 AXG
36 Flow Noise2 Hi/Lo Limit FLN.2 AXG
37 Cond.1 Hi/Lo Limit Cond.1 AXG
38 Cond.2 Hi/Lo Limit Cond.2 AXG
39 Adhesion Warn Status Adh.Warn AXG / AXW
40 Adhesion Alarm Status Adh.Alm AXG / AXW
41 Flow Noise Warn Status FLN.Warn AXG
42 Flow Noise Alm Status FLN.Alm AXG
43 Low Conductivity Warn Status LoCndc.Warn AXG
A channel can be selected in each DI function block with the following parameter.
Display Devicesetup►Detailedsetup►Fieldbusinfo►DIxFB*►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►DI1*►DeviceConguration►Conguration►(seebelow)
*One from DI1 to DI3.
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
DI1* 15 Channel CHANNEL
Selects CHANNEL number
used in the DI function block.
Refer to Table 5.3.1 for
Selection.
*One from DI1 to DI3.
