YOKOGAWA ADMAG TI Series User Manual

<Appendix 4. Link Master Functions>
271
IM 01E21A02-03EN
Index(SM) Parameter Name
Sub-parameter Name
(Sub Index)
Default Value
Write
mode
Description/
Remarks
291 BOOT_OPERAT_
FUNCTIONAL_
CLASS
Speciedatthetime
of ordering
RW 0x01(basic
device);0x02(LM)
292 CURRENT_LINK_
SETTING_RECORD
0 R Settings for LAS
1 SlotTime 0
2 PerDlpduPhlOverhead 0
3 MaxResponseDelay 0
4 FirstUnpolledNodeId 0
5 ThisLink 0
6 MinInterPduDelay 0
7 NumConseeUnpolledNodeId 0
8 PreambleExtension 0
9 PostTransGapExtension 0
10 MaxInterChanSignalSkew 0
11 TimeSyncClass 0
293 CONFIGURED_
LINK_
SETTING_RECORD
0 RW
1 SlotTime 4095
2 PerDlpduPhlOverhead 4
3 MaxResponseDelay 5
4 FirstUnpolledNodeId 37
5 ThisLink 0
6 MinInterPduDelay 12
7 NumConseeUnpolledNodeId 186
8 PreambleExtension 2
9 PostTransGapExtension 1
10 MaxInterChanSignalSkew 0
11 TimeSyncClass 4
294 LINK_SCHEDULE_ACTIVATION_VARIABLE 0(0x0) RW
295 LINK_
SCHEDULE_LIST_
CHARACTERISTICS_
RECORD
0 R
1 NumOfSchedules 2
2 NumOfSubSchedulesPerSchedule 5
3 ActiveScheduleVersion 0
4 ActiveSheduleOdIndex 0
5 ActiveScheduleStartingTime 0
296 DLME_SCHEDULE_
DESCRIPTOR.1
0 R
1 Version 0
2 MacrocycleDuration 0
3 TimeResolution 0
297 DLME_SCHEDULE_
DESCRIPTOR.2
0 R
1 Version 0
2 MacrocycleDuration 0
3 TimeResolution 0
298 DOMAIN.1 Read/write
impossible.
Get-OD is possible.
299 DOMAIN.2 Read/write
impossible.
Get-OD is possible.
