<5. Functions>
110
IM 01E21A02-03EN
Display FOUNDATION Fieldbus
Default Value Attribute
Parameter
Name
Alarm Name
Parameter
Name
Alarm Name
Mask 3-2 106:SD removal ERR Alarm out mask 3
microSD card removal
procedure error
 
Mask 3-2 120:Watchdog
*1
Alarm out mask 3 Watchdog
*1
 
Mask 3-2 121:Powero󰀨
*1
Alarm out mask 3 Powero󰀨
*1
 
Mask 3-2 122:Inst power FAIL
*1
Alarm out mask 3 Instant power failure
*1
 
Mask 3-2 123:Param bkup run Alarm out mask 3
Parameter backup
running
 
Mask 3-2 124:Data log run Alarm out mask 3 Data logging running
 
Mask 4-1 133:G/A mismatch Alarm out mask 4 G/A mismatch error
 
*1: Recordedinthealarmrecordregardlessofthesettingsofthealarmnoticationmaskfunction.
 Alarm record mask function
Display FOUNDATION Fieldbus
Default Value Attribute
Parameter
Name
Alarm Name
Parameter
Name
Alarm Name
- 010:Main CPU FAIL -
Main board CPU
failure
- -
- 011:Rev calc FAIL -
Reverse calculation
failure
- -
- 012:Main EEP FAIL -
Main board EEPROM
failure
- -
Mask 1-1 013:MainEEPdt
Alarm record
mask 1
Main board EEPROM
default
-

- 014:Snsr bd FAIL - Sensor board failure - -
- 015:Snsr comm ERR -
Sensor
communication error
- -
- 016:AD1FAIL[Sig] - A/D1failure[Signal] - -
- 017:AD2FAIL[Excit] - A/D2failure[Exciter] - -
- 018:Coil open - Coil open - -
- 019:Coil short - Coil short - -
- 020:Exciter FAIL
Alarm record
mask 1
Exciter failure - -
- 027:Restore FAIL -
Parameter restore
incomplete
- -
Mask 1-2 028:Ind bd FAIL
Alarm record
mask 1
Indicator board failure -

Mask 1-2 029:Ind bd EEP FAIL
Alarm record
mask 1
Indicator board
EEPROM failure
-

Mask 1-2 030:LCD drv FAIL
Alarm record
mask 1
LCD driver failure -

Mask 1-2 031:Ind bd mismatch
Alarm record
mask 1
Indicator board
mismatch
-

Mask 1-2 032:Ind comm ERR
Alarm record
mask 1
Indicator
communication error
-

Mask 1-2 033:microSD FAIL
Alarm record
mask 1
microSD failure -

Mask 2-1 050:Signaloverow
Alarm record
mask 2
Signaloverow -

Mask 2-1 051:Empty detect
Alarm record
mask 2
Empty pipe detection -

Mask 2-1 053:Adh over lv 4
Alarm record
mask 2
Adhesion over level 4 -

- 060:Span cfg ERR -
Spanconguration
error

-
