<2. About Fieldbus>
14
IM 01E21A02-03EN
(4) Local Display transducer block (LTB)
• Controls the display.
(5) Maintenance transducer block (MTB)
• Is related to settings for detailed device information and manufacturing.
• Hasfunctionstodisplaydeviceinformation(detailedversionofthedevice,serialNo.
information,etc.),informationrelatedtoeventmanagement(backup/restore,datalogging
function),applicationforservice/factory/expert(fordebugging,manufacturing),alarm/error
log and software download results.
(6) AI function block (AIFB) (AXG: 4, AXW: 3)
• Outputsvariousowrates(includingowvelocity),calorieandtotalizedvalue.
• ForAXG,outputstheadhesionresistance,electrodepotential,ownoiseandconductivity.
• PerformsprocessingsuchastheSIMULATEfunction,damping(rst-orderlaglter),
scaling, etc.
(7) Dl function block (DIFB) (3)
• Performs discrete output for the process value, alarm and warning of STB and DTB.
(8) PID function block
• Performs the PID control computation based on the deviation of the measured value from
the setpoint.
(9) MAO function block (only AXG)
• Inputs a temperature value from other device.
(10) IT function block (2)
• Adds two main inputs and integrates them for output.
(11) AR function block
• Switchestwomaininputsofdi󰀨erentmeasurementrangesbumplesslyandcombinesthe
result with three auxiliary inputs through the selected compensation function to calculate the
output.
Indexes of each block are shown below:
Block Start Index
Resource block 1000
Sensor transducer block 2000
Diagnosis transducer block 2500
Local Display transducer block 2700
Maintenance transducer block 2900
AI1 function block 4000
AI2 function block 4100
AI3 function block 4200
AI4 function block 4300
DI1 function block 6000
DI2 function block 6100
