 List of sensor transducer block parameter bit
Label
Bit
Selection
Parameter
Name
Display
F
OUNDATION
Fieldbus
Display
F
OUNDATION
Fieldbus
ALM_OUT_
MASK1
Mask1-1(bit28)
Mask1-2(bit1-6)
Alarm Out Mask1 bit:28 013:MainEEPdt MainEEPdton
bit:6 028:Ind bd FAIL Ind bd FAIL on
bit:5 029:Ind bd EEP FAIL Ind EEP FAIL on
bit:4 030:LCD drv FAIL LCD drv FAIL on
bit:3 031:Ind bd mismatch Ind mismatch on
bit:2 032:Ind comm ERR Ind comm ERR on
bit:1 033:microSD FAIL SD FAIL on
ALM_OUT_
MASK2
Mask2-1(bit31
-17)
Mask2-2(bit15-0)
Alarm Out Mask2 bit:31 050:Signaloverow Sigoverowon
bit:30 051:Empty detect Empty detect on
bit:28 053:Adh over lv 4 Adh over lv4 on
bit:23 060:Span cfg ERR Span cfg ERR on
bit:17 066:Density cfg ERR Dens cfg ERR on
bit:15 067:Pls 1 cfg ERR Pls1 cfg ERR on
bit:13 069:Nomi size cfg Nomi size cfg on
bit:12 070:Adh cfg ERR Adh cfg ERR on
bit:11 071:FLN cfg ERR FLN cfg ERR on
bit:10 072:Log not start Log not start on
bit:5 082:Pls 1 saturate Pls1 saturte on
bit:2 085:Cable miscon Cable miscon on
bit:1 086:Coil insulation Coil insu on
bit:0 131:Trans mismatch Trn mismatch on
ALM_OUT_
MASK3
Mask3-1(bit31
-20)
Mask3-2(bit15-3)
Alarm Out Mask3 bit:31 087:Adhesion lv 3 Adh over lv3 on
bit:30 088:LC warn LC warn on
bit:29 089:Insu detect Insu detect on
bit:28 090:FLN over lv 3 FLN over lv3 on
bit:27 091:FLN over lv 4 FLN over lv4 on
bit:26 092:AZ warn AZ warn on
bit:25 093:Verif warn Verif warn on
bit:24 094:Fact noise warn FC noise warn on
bit:23 095:Simulate active Sim active on
bit:20 098:Pls1x Pls1xon
bit:15 101:Param restore run Restore run on
bit:14 102:Disp over Disp over on
bit:13 103:SD size warn SD size warn on
bit:12 104:Bkup incmplt Bkup incmplt on
bit:11 105:SD mismatch SD mismatch on
bit:10 106:SD removal ERR SD remov ERR on
bit:7 120:Watchdog Watchdog on
bit:6 121:Powero󰀨 Powero󰀨on
bit:5 122:Inst power FAIL Inst PW Fail on
bit:4 123:Param bkup run Prm bkup run on
bit:3 124:Data log run Data log run on
ALM_OUT_
MASK4
Mask 4-1 Alarm Out Mask4 bit: 21
133:G/A mismatch
G/A mismatch error
