<6. Parameter Lists>
199
IM 01E21A02-03EN
Label
Value
Selection
Parameter
Name
Display F
OUNDATION Fieldbus Display
F
OUNDATION
Fieldbus
DISP_LINE2_
SEL
Line 2
Display Line Select 2 0 None None
DISP_LINE3_
SEL
Line 3
Display Line Select 3 1 Flowrate(%) Flowrate(%)
DISP_LINE4_
SEL
Line 4
Display Line Select 4 2 PV PV
DISP_LINE5_
SEL
Line 5
Display Line Select 5 3 Velocity Velocity
DISP_LINE6_
SEL
Line 6
Display Line Select 6 4 Volume Volumeow
DISP_LINE7_
SEL
Line 7
Display Line Select 7 5 Mass Massow
DISP_LINE8_
SEL
Line 8
Display Line Select 8 6 Flowrate(%Bar) Flowrate(%Bar)
7 Calorie Calorie
9 Totalizer 1 Totalizer1
10 Totalizer 2 Totalizer2
12 PD Tag PD Tag
13 Commun protocol Commun Protocol
14 Adhesion Adhesion
17 Flow noise level ownoiselevel
19 Totalizer 1 count Totalizer 1 count
20 Totalizer 2 count Totalizer 2 count
22 AI1 Flow rate AI1 Flow rate
23 AI1Flowrate(%) AI1Flowrate(%)
24 AI1 Flow
rate(%Bar)
AI1 Flow
rate(%Bar)
25 AI1.OUT AI1.OUT
26 AI2.OUT AI2.OUT
27 AI3.OUT AI3.OUT
28 AI4.OUT AI4.OUT
29 IT1.OUT IT1.OUT
30 IT2.OUT IT2.OUT
31 AR.OUT AR.OUT
DISP_FORMAT_
FR
Format PV Display Format Flow
Rate
0 Auto Auto
1 0 digit 0 digit
2 1 digit 1 digit
3 2 digit 2 digit
4 3 digit 3 digit
5 4 digit 4 digit
6 5 digit 5 digit
7 Auto 2 Auto 2
DISP_FORMAT_
TTL1
DISP_FORMAT_
TTL2
Format total 1
Format total 2
Display Format Total 1
Display Format Total 2
0 Auto Auto
1 0 digit 0 digit
2 1 digit 1 digit
3 2 digit 2 digit
4 3 digit 3 digit
5 4 digit 4 digit
6 5 digit 5 digit
7 6 digit 6 digit
8 7 digit 7 digit
