YOKOGAWA ADMAG TI Series

<6. Parameter Lists>
201
IM 01E21A02-03EN
Label
Value
Selection
Parameter
Name
Display F
OUNDATION Fieldbus Display
F
OUNDATION
Fieldbus
DISP_TREND_
SEL1
Trend 1 Display Trend Select 1 0 Flowrate(%) Flowrate(%)
1 PV PV
2 Velocity Velocity
3 Volume Volumeow
4 Mass Massow
5 Calorie Calorie
9 Totalizer 1 Totalizer1
10 Totalizer 2 Totalizer2
DISP_TREND_
SEL2
DISP_TREND_
SEL3
DISP_TREND_
SEL4
Trend 2
Trend 3
Trend 4
Display Trend Select 2
Display Trend Select 3
Display Trend Select 4
0 None None
1 Flowrate(%) Flowrate(%)
2 PV PV
3 Velocity Velocity
4 Volumeow Volumeow
5 Massow Massow
9 Calorie Calorie
10 Totalizer 1 Totalizer1
11 Totalizer 2 Totalizer2
DISP_INVERSE Inversion Display Inversion 0 Normal Normal
1 Invert Invert
LCD_TEST
*
LCD test LCD Test 0 Not execute Not Execute
1 Execute Execute all
2 Show pattern 1 Show Pattern1
3 Show pattern 2 Show Pattern2
4 Show pattern 3 Show Pattern3
5 Show pattern 4 Show Pattern4
SQUAWK Squawk Squawk 0 O󰀨 O󰀨
1 On On
2 Squawk once Squawk once
LANGUAGE_
PACKAGE
Language package Language Package 0 Pack 1 Pack 1
1 Pack 2 Pack 2
DISP_INSTALL Disp install Display Install 0 No disp No disp
1 With disp With disp
DISP_IRSW_
OPERATE
- IRSW Operate 0 - Disable
1 Enable
*: LCD_TEST operates in the following ways based on selections.
Not Execute : Does not perform test display
 Executeall :Testdisplay(Alllightson►Alllightso󰀨►Houndstooth►Houndstooth(inversion))
 ShowPattern1 :Testdisplay(Alllightson)
 ShowPattern2 :Testdisplay(Alllightso󰀨)
 ShowPattern3 :Testdisplay(Houndstooth)
 ShowPattern4 :Testdisplay(Houndstooth(inversion))
