YOKOGAWA ADMAG TI Series User Manual

<6. Parameter Lists>
206
IM 01E21A02-03EN
Relative
Index
Index Parameter Name Default Value
Write
Mode
Description
99 2999
SO1_TEST_
VALUE
0(Open) AUTO See 5.10.2.
100 3000 TEST_2_MODE 0(Normal) AUTO See 5.10.2.
101 3001 TEST_2_OUT 0.0 AUTO See 5.10.2.
102 3002 P1_OUT_MODE 1(FixedPulseOutput) AUTO See 5.14.1.
103 3003 P1_ACT_MODE 0(OnActive) AUTO See 5.14.4.
104 3004 P1_WIDTH 0(0.05ms) AUTO See 5.14.3.
105 3005 P1_RATE_UNIT 3(Unit/P) AUTO See 5.14.5.
106 3006 P1_RATE_VAL 1.0 AUTO See 5.14.5.
107 3007 P1_LOW_CUT 0.0 AUTO See 5.1.7.
108 3008
P1_LOW_CUT_
UNIT
1349(m
3
/h) -
Indicates the unit of the
physical quantity assigned
toPulse1.(Valuefor
the unit of the physical
quantity selected in Sensor
TB.SELECTED_FLOW)
109 3009 P1_ALM_OUT 0(0pps) AUTO See 5.14.2.
110 3010 F1_AT_0 0 AUTO See 5.14.6.
111 3011 F1_AT_100 0 AUTO See 5.14.6.
112 3012 SO1_FUNC 0(Nofunction) AUTO See 5.14.7.
113 3013 P1_OPTS 2(Onlypositive) AUTO
Selects the totalization mode
for P1.
 List of selection for maintenance transducer block parameter
Label
Value
Selection
Parameter Name Display
F
OUNDATION
Fieldbus
Display F
OUNDATION Fieldbus
SOFTDL_
PROTECT
- Soft DL Protect 1 - Unprotected
2 Protected
SOFTDL_ACT_
AREA
- Soft DL Act Area 0 - Area 0
1 Area 1
SI_CONTROL_
CODES
SI unit SI Control Codes 0 SI SI Units only
1 All All
2 JPonly JPonly
