YOKOGAWA ADMAG TI Series User Manual

<Appendix 4. Link Master Functions>
274
IM 01E21A02-03EN
(9) PlmeBasicCharacteristics
Sub-index Element Size [B] Value Description
1
Channel
Statistics
Supported
1 0 Statistics information are not supported.
2
Medium
AndData
Rates
Supported
8 0x490000000000000
Wire medium, voltage mode, and 31.25
kbps are supported.
3 IceVersion 2 1
Indicates the version for IEC Physical Layer
Entity.
4
NumOf
Channels
1 1
5
Power
Mode
1 1
0: Bus Powered
1: Self Powered
(10) ChannelStates
Sub-index Element Size [B] Value Description
1 Channel 1 1 0x00
In Use,
No Bad since last read,
No Silent since last read,
NoJabbersincelastread,
Tx Good, Rx Good
2 Channel 2 1 0x80 Unused
3 Channel 3 1 0x80 Unused
4 Channel 4 1 0x80 Unused
5 Channel 5 1 0x80 Unused
6 Channel 6 1 0x80 Unused
7 Channel 7 1 0x80 Unused
8 Channel 8 1 0x80 Unused
(11) PlmeBasicInfo
Sub-index Element Size [B] Value Description
1 InterfaceMode 1 0
0: Half Duplex
1: Full Duplex
2 LoopBackMode 1 0
0: Disabled
1: MAU
2: MDS
3 XmitEnabled 1 0x01 Channel 1 is enabled.
4 RcvEnebled 1 0x01 Channel 1 is enabled.
5
PreferredReceive
Channel
1 0x01 Channel 1 is used for reception.
6
MediaType
Selected
1 0x49
wire medium, voltage mode,
31.25 kbps are selected.
7 ReceiveSelect 1 0x01 Channel 1 is used for reception.
(12) LinkScheduleActivationVaribale
Writing the version number of an LAS schedule, which has already been downloaded to the
domain, to this parameter causes the corresponding schedule to be executed.
On the other hand, writing 0 to this parameter stops the active schedule which is being
executed.
