Relative
Index
Parameter Name
View
1 2 3 4
54 FD_OFFSPEC_MASK 4
55 FD_MAINT_MASK 4
56 FD_CHECK_MASK 4
57 FD_FAIL_ALM
58 FD_OFFSPEC_ALM
59 FD_MAINT_ALM
60 FD_CHECK_ALM
61 FD_FAIL_PRI 1
62 FD_OFFSPEC_PRI 1
63 FD_MAINT_PRI 1
64 FD_CHECK_PRI 1
65 FD_SIMULATE 9
66 FD_RECOMMEN_ACT 2 2
67
FD_EXTENDED_
ACTIVE_1
68
FD_EXTENDED_
ACTIVE_2
69
FD_EXTENDED_
ACTIVE_3
70
FD_EXTENDED_
ACTIVE_4
71
FD_EXTENDED_
ACTIVE_5
72
FD_EXTENDED_
ACTIVE_6
73
FD_EXTENDED_
ACTIVE_7
74
FD_EXTENDED_
ACTIVE_8
75
FD_EXTENDED_
MAP_1
76
FD_EXTENDED_
MAP_2
77
FD_EXTENDED_
MAP_3
78
FD_EXTENDED_
MAP_4
79
FD_EXTENDED_
MAP_5
80
FD_EXTENDED_
MAP_6
81
FD_EXTENDED_
MAP_7
82
FD_EXTENDED_
MAP_8
83
DEVICE_CONDITION_
ACTIVE_1
84
DEVICE_CONDITION_
ACTIVE_2
85
DEVICE_CONDITION_
ACTIVE_3
86
DEVICE_CONDITION_
ACTIVE_4
87
DEVICE_CONDITION_
ACTIVE_5
88
DEVICE_CONDITION_
ACTIVE_6
89
DEVICE_CONDITION_
ACTIVE_7
90
DEVICE_CONDITION_
ACTIVE_8
91 SOFTWARE_REV
92 WRITE_LOCK_LEVEL
Total 40 30 49 69
Table 4.11 View Object for Resource Block
Relative
Index
Parameter Name
View
1 2 3 4
1 ST_REV 2 2 2 2
2 TAG_DESC
3 STRATEGY 2
4 ALERT_KEY 1
5 MODE_BLK 4 4
6 BLOCK_ERR 2 2
7 RS_STATE 1 1
8 TEST_RW
9 DD_RESOURCE
10 MANUFAC_ID 4
11 DEV_TYPE 2
12 DEV_REV 1
13 DD_REV 1
14 GRANT_DENY 2
15 HARD_TYPES 2
16 RESTART
17 FEATURES 2
18 FEATURE_SEL 2
19 CYCLE_TYPE 2
20 CYCLE_SEL 2
21 MIN_CYCLE_T 4
22 MEMORY_SIZE 2
23 NV_CYCLE_T 4
24 FREE_SPACE 4
25 FREE_TIME 4 4
26 SHED_RCAS 4
27 SHED_ROUT 4
28 FAULT_STATE 1 1
29 SET_FSTATE
30 CLR_FSTATE
31 MAX_NOTIFY 1
32 LIM_NOTIFY 1
33 CONFIRM_TIME 4
34 WRITE_LOCK 1
35 UPDATE_EVT
36 BLOCK_ALM
37 ALARM_SUM 8 8
38 ACK_OPTION 2
39 WRITE_PRI 1
40 WRITE_ALM
41 ITK_VER 2
42 COMPATIBILITY_REV
43 CAPABILITY_LEV
44 FD_VER 2
45 FD_FAIL_ACTIVE 4 4
46 FD_OFFSPEC_ACTIVE 4 4
47 FD_MAINT_ACTIVE 4 4
48 FD_CHECK_ACTIVE 4 4
49 FD_FAIL_MAP 4
50 FD_OFFSPEC_MAP 4
51 FD_MAINT_MAP 4
52 FD_CHECK_MAP 4
53 FD_FAIL_MASK 4
