  <4.Conguration>
36
IM 01E21A02-03EN
Table 4.13 View Object for Diagnosis Transducer Block
Relative
Index
Parameter Name
View
1 2 3-1 3-2 4-1 4-2
1 ST_REV 2 2 2 2 2 2
2 TAG_DESC
3 STRATEGY 2
4 ALERT_KEY 1
5 MODE_BLK 4 4
6 BLOCK_ERR 2 2
7 UPDATE_EVT
8 BLOCK_ALM
9 TRANSDUCER_DIRECTORY
10 TRANSDUCER_TYPE 2 2 2 2
11 TRANSDUCER_TYPE_VER 2
12 XD_ERROR 1 1
13 COLLECTION_DIRECTORY
14 ADHESION_VALUE 5 5
15 ADHESION_VALUE_UNIT 2
16 ELECTRODE_A_VALUE 5 5
17 ELECTRODE_A_VALUE_UNIT 2
18 ELECTRODE_B_VALUE 5 5
19 ELECTRODE_B_VALUE_UNIT 2
20 FLOW_NOISE_VALUE 5 5
21 FLOW_NOISE_VALUE_UNIT 2
22 CONDUCTIVITY_VALUE 5 5
23 CONDUCTIVITY_VALUE_UNIT 2
24 ADHESION_CHECK 1
25 ADHESION_LEVEL1 4
26 ADHESION_LEVEL2 4
27 ADHESION_LEVEL3 4
28 ADHESION_LEVEL4 4
29 ADHESION_STATUS 1
30 ADHESION_CHECK_CYCLE 1
31 FLOW_NOISE_CHECK 1
32 FLOW_NOISE_LEVEL1 4
33 FLOW_NOISE_LEVEL2 4
34 FLOW_NOISE_LEVEL3 4
35 FLOW_NOISE_LEVEL4 4
36 FLOW_NOISE_STATUS 1
37 FLOW_NOISE_DAMPING 4
38 LOW_CONDUCT_CHECK 1
39 CONDUCTIVITY_LIMIT 4
40 DIAG_EXECUTION 1
41 COIL_INSULATION_TH 4
42 IEX_COMPARE 4
43 PEAK_HOLD_VALUE 4
44 IEX_COIL_RESISTANCE 4
45 EMPTY_STS 1
46 DIAG_OUTPUT 1
47 VERIFICATION_TARGET 2
48 VERIFICATION_MODE 1
49 VERIFICATION_EXE 1
50 VERIFICATION_NO 1
51 VERIFICATION_CHECK_RESULT 1
52 VERIFICATION_OPERATION_TIME 16
53 MAGNETIC_CIRCUIT_RESULT 1
54 EXCITING_CIRCUIT_RESULT 1
55 CALCULATION_CIRCUIT_RESULT 1
56 DEVICE_STATUS_RESULT 1
57 CONNECTION_STATUS_RESULT 1
58 LIMIT_STS_ADH1_VALUE 2
59 LIMIT_STS_ADH1_SETPOINT 4
60
LIMIT_STS_ADH1_ACT_
DIRECTION
1
61 LIMIT_STS_ADH1_HYSTERESIS 4
62 LIMIT_STS_ADH1_UNIT 2
63 LIMIT_STS_ADH2_VALUE 2
64 LIMIT_STS_ADH2_SETPOINT 4
65
LIMIT_STS_ADH2_ACT_
DIRECTION
1
66 LIMIT_STS_ADH2_HYSTERESIS 4
67 LIMIT_STS_ADH2_UNIT 2
68 LIMIT_STS_ELEC_A1_VALUE 2
69 LIMIT_STS_ELEC_A1_SETPOINT 4
70
LIMIT_STS_ELEC_A1_ACT_
DIRECTION
1
