Table 4.15 View Object for Maintenance Transducer Block
Relative
Index
Parameter Name
View
1 2 3-1 3-2 4-1 4-2 4-3 4-4 4-5 4-6
1 ST_REV 2 2 2 2 2 2 2 2 2 2
2 TAG_DESC
3 STRATEGY 2
4 ALERT_KEY 1
5 MODE_BLK 4 4
6 BLOCK_ERR 2 2
7 UPDATE_EVT
8 BLOCK_ALM
9
TRANSDUCER_
DIRECTORY
10 TRANSDUCER_TYPE 2 2 2 2
11
TRANSDUCER_
TYPE_VER
2 2 2 2
12 XD_ERROR 1 1
13
COLLECTION_
DIRECTORY
14 DEVICE_KEY
15 DEVICE_SN 32
16 SPECIAL_ORDER_ID 32
17 MANUFAC_DATE 7
18 MS_CODE1
19 MS_CODE2
20 MS_CODE3
21 SOFTWARE_DESC
22 SIM_ENABLE_MSG 32
23 SOFTDL_PROTECT 1
24 SOFTDL_ERROR 2
25 SOFTDL_COUNT
26 SOFTDL_ACT_AREA
27 CAPABILITY_CONFIG
28 SI_CONTROL_CODES 1
29
COMSTACK_
STATISTICS_1
30
COMSTACK_
STATISTICS_2
31 EXEC_FB_CNT
32 FB_TEMP_DEV_ID
33 FD_EXTENDED_SIM
34 FD_1
35 FD_2
36 FD_3
37 FD_4
38 FD_5
39 FD_6
40 FD_7
41 FD_8
42 EEPROM_STATE
43 INITIALIZE_EEPROM
44 READ_MEMORY
45 WRITE_MEMORY
46 OPERATE_TIME 16
47 TRNS_TYPE 1
48 EL_SIZE 1
49 EX_PROTECTION 1
50 MODEL_CODE 16
