YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
58
IM 01E21A02-03EN
 Pulse output/totalization
Menu path
Display Devicesetup►Detailedsetup►Provar►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►STB►DeviceConguration►Conguration►Process
Variables►Density►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 40 Velocity►Damppls/ttl Velocity►VelocityDampingTtl
Speciesthedamping
time constant of the
owvelocitypulse/
totalized value.
STB 32 Volume►Damppls/ttl
VolumeFlow►VolumeF
Damping Total
Speciesthedamping
time constant of the
volumetricowrate
pulse/totalized value.
STB 36 Mass►Damppls/ttl
MassFlow►MassFDamping
Total
Speciesthedamping
time constant of the
massowratepulse/
totalized value.
STB 44 Calorie►Damppls/ttl Calorie►CaloricDampingTtl
Speciesthedamping
time constant of the
calorie pulse/totalized
value(onlyavailable
forAXG,notforAXW).
 Flow noise
Menu path
Display Devicesetup►Diag/Service►Diagnosis►Flownoise►(seebelow)
F
OUNDATION
Fieldbus
Diagnostic►DTB►DeviceDiagnostics►Diagnostics/Alerts►Diagnostics►Flow
Noise►(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
DTB 37 Damp Flow Noise Damping
Speciesthedampingtime
constantofownoise(only
available for AXG, not for
AXW).
 AI FB output
Menu path
Display Devicesetup►Detailedsetup►Fieldbusinfo►AI1FB*►(seebelow)
F
OUNDATION
Fieldbus
DeviceConguration►AI1*►DeviceConguration►Conguration►BasicSettings►
(seebelow)
*For AXG, one from Al1 to Al4, and for AXW, one from AI1 to AI3.
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
AI1 - AI4
(AXG)
AI1 - AI3
(AXW)
18 PV_FTIME Process Value Filter Time
Speciesthedampingtime
constant of the AI FB output.
