Zebra ZD620 - PASSWORD PROTECT

To Next Page

To Previous Page

101

Printer Configuration Menus

PASSWORD PROTECT

Description: Select the level of password protection for user menu items. The default

printer password is

1234.

Accepted values:

NONE, SELECTED, ALL

Related ZPL command(s): ^KP (to change the printer password)
