Printer Features

ZD620 and ZD420 Locking Printer Features

This option is only available in a Healthcare ZD620 printer model. It includes a lock and

key access to the printer’s media compartment and a Kensington Lock Slot on the back

panel of the printer to secure the printer. For more information on the Locking Printer

option, see ZD620 and ZD420 Locking Printer Option.

Kensington Lock Slot

Cabinet Lock
