IP ALTERNATE PORT

Description: This command sets the port number of the alternate TCP port.

SGD command used: internal_wired.ip.port_alternate

Printer Web page: View and Modify Printer Settings

> Network Communications Setup >

TCP/IP Settings

Note • Print servers supporting this command will monitor both the primary port and the

alternate port for connections at the same time.
